Managing Device
The device is equipped with a touch-display, an encoder and two push buttons for
local control. For remote operation a network socket is provided at the rear panel
to operate the device via a browser based GUI or via globcon.
HOME
BACK
Display
CONTROL
Push-button to access the HOME screen.
Press shortly to call the top menu.
Push-button to return to previous page.
Press shortly to return to the previous page.
Touch-Display to navigate the menu, adjust
settings and for monitoring.
tap, swipe - have fun!
Encoder to adjust values and confi rmation.
Rotate to modify values. Press to confi rm a setting.
Prodigy.MC Hardware Guide - Version 1.0
CHAPTER 4: Operation
