AN8.I
LINE INPUT
MIC8.HD.I
MIC / LINE INPUT
The pinout complies with AES59 ('TASCAM pinout')
Pin assignment" on page 58.
Prodigy.MC Hardware Guide - Version 1.0
DSUB-25 Port (analog pinout)
Analog audio input (balanced) -
connect line level audio source here
DSUB-25 Port (analog pinout)
Analog audio input (balanced) -
connect mic / line level audio source here
-
see „Appendix A - DSUB-25
CHAPTER 4: Operation
page 41 of 64
