BREAKOUT.AES - digital input / output, 8 AES3 ports (16 channels)
Article Code: DOBOB0718
BREAKOUT.AESID - digital input / output, 16 AESid ports (32 channels)
Article Code: DOBOB0722
Patch Chords
Cabling from Cordial provides appropriate connection of the BREAKOUT with your
device to ensure proper transmission of the audio signals.
Name Description
DSUB25.AN50 Analog patch cable for connection
with BREAKOUT.AN16I, AN16O, AN8,
transferring 8 audio channels, length 0.5 m
DSUB25.AN100 Analog patch cable for connection
with BREAKOUT.AN16I, AN16O, AN8,
transferring 8 audio channels, length 1.0 m
DSUB25.AES50 Digital patch cable for connection with
BREAKOUT.AES or AESid
transferring 8 audio channels, length 0.5 m
DSUB25.AES100 Digital patch cable for connection with
BREAKOUT.AES or AESid
transferring 8 audio channels, length 0.5 m
