Slots - MADI Modules

Two MADI slots offer the choice between three connection standards for
transmission of 64 channels @ 1 FS.
Module Module
BNC.IO BNC.IO
SFP .IO SFP .IO
SC.IO SC.IO
BNC.IO BNC.IO
SC.IO SC.IO
SFP .IO SFP .IO
* matching SFP modules available from DirectOut - see page 17 .
** The SC ports are multi-mode as default, single-mode SC ports are available on
request. The housing of single-mode ports is colored blue.
multi-mode
Connection Connection
coaxial BNC input / output 75 Ω coaxial BNC input / output 75 Ω
SFP cage * SFP cage *
SC-socket duplex multi-mode ** SC-socket duplex multi-mode **
single-mode
