AES4.IO
AES3 INPUT / OUTPUT
AES4.SRC.IO
AES3 INPUT (SRC) /
OUTPUT
The pinout complies with AES59 ('TASCAM pinout')
Pin assignment" on page 58.
DSUB-25 Port (digital pinout)
Digital audio input and output (AES3) -
connect for digital audio here
DSUB-25 Port (digital pinout)
Digital audio input and output (AES3) -
connect for digital audio here.
Input offers switchable Sample Rate Conversion.
Prodigy.MC Hardware Guide - Version 1.0
CHAPTER 4: Operation
-
