Refer to the appropriate panel programming guide as needed. Keep in mind that
operation for some programming options is restricted to the appropriate model. To
program a keypad, access the Installer Options menu by pressing and holding the CMD
and back arrow keys at the same time for two seconds. At SET BRIGHTNESS, enter
3577 (INST) and CMD for XR150INT/XR550INT Series panels or enter 357 and CMD for
XT30INT Series panels.
KEYPAD OPTIONS
KPD KPD
OPT DIAG
CURRENT KEYPAD
ADDRESS: 1
13
PROGRAM THE KEYPAD
Keypad Options
To program keypad options, press the select key under
STOP
KPD OPT.
Current Keypad Address
Set the current keypad address from 01 to 08 for XT30INT
or XR150INT Series panels, or 01 to 16 for XR550INT Series
panels. The default address is set at 01. To change the
current address, press any select key to clear the keypad
display, enter the new address, and press CMD. Do not enter
a leading zero for addresses 01 to 09.
Digital Monitoring Products, Inc | 7000INT Series Installation and Programming Guide
