Normally Closed
+
–
Model 333
Magnetic Door Lock
Supressor
Figure 5a: Typical Magnetic Lock Wiring
7000INT Series Installation and Programming Guide | Digital Monitoring Products, Inc.
C
NO
NC
Power Supply
Normally Open
NO
+
–
Model 333
Door Strike Relay
Supressor
Figure 5b: Typical Door Strike Wiring
C
NC
Power Supply
10
