SITE CODE
POS: 1
LEN: 8
USER CODE
POS: 9
LEN: 16
REQUIRE SITE
NO YES
CODE:
7000INT Series Installation and Programming Guide | Digital Monitoring Products, Inc.
Site Code Position and Length
Enter the site code start position and length in the data
string. Press select key 2 to clear the site code start position
and enter a number between 0-255. Press CMD to save.
Default is 1.
Press select key 4 to clear the site code length and enter a
number between 1-24. Press CMD to save. Default is 8.
User Code Position and Length
Define the user code start bit position and length. Press
select key 2 to clear the user code position and enter a
number between 0-255. Press CMD to save. Default is 9.
Press select key 4 to clear the user code length and enter
a number between 16-64. Press CMD to save. The default is
the DMP value of 16.
Require Site Code
Press the select key under YES to use a site code and
press CMD to view the site code entry display. Press NO to
advance to NO OF USER CODE DIGITS. Default is NO.
In addition to user code verification, door access is only
granted when any one site code programmed at the
SITE CODE option matches the site code received in the
Wiegand string.
20
