SITE CODE 1:
NO OF USER CODE
DIGITS:
NO COMM WITH PNL
OFF SITE ANY ON
21
Site Code
You can program up to eight 8-digit site codes. The site code
range is 0-16,777,214.
In the keypad display, enter site code 1 and press CMD. The
display will ask for site code 2 followed by site code 3 and
so on. When you have selected the site code you want to
change, press CMD.
Number of User Code Digits
The keypad recognizes user codes from 4-12 digits in length.
5
Press any select key to clear the keypad display and enter
the user code digit length being used by the panel. Default
is 5. For an XR150INT/XR550INT area type, use 4-10 digits
(typically 5). For all other systems and panels, use 4 digits.
No Communication with Panel
Define the relay action when communication with the panel
has not occurred for 5 seconds. Default is OFF. Press any
select key to change the default relay action:
Press the first select key to choose OFF (Relay Always
Off). The relay does not turn on when any Wiegand string
is received. OFF does not affect any REX operation. If
communication is lost during a door strike, the relay remains
on for the door strike duration but turns off at the end of the
door strike timer.
