Program The Keypad; Reading The Display; User Options - DMP Electronics Thinline 7300 Series Installation And Programming Manual

Reading the Display

For programming options, the display shows an identifier
followed by a value. The identifier represents the menu option
and the value represents the currently-programmed value. For
options that can be turned off or on, the values are binary where
0 = off and 1 = on.
For more information, refer to each of the following sections or
Reference.

User Options

To access User Options, hold down the back arrow and CMD keys for two seconds. Press
CMD to display the next option or press the Back Arrow to exit the User Options menu.
8

PROGRAM THE KEYPAD

Brightness
Set the brightness of the display, keyboard, and logo backlighting
by selecting a level between 0 (off) and 8 (max). The default is 8.
The brightness level increases to maximum intensity when a key is
pressed. If no activity occurs for 30 seconds, brightness returns to
the programmed level.
Digital Monitoring Products, Inc | 7300 Series Installation and Programming Guide
Identifier Value
Examples
Brightness = 8
Panic Key = On
