External Reader/Door Strike
7073-WINT Keypads
Connect Reader Data 0
Connect Reader Data 1
Door Strike Normally Open
Door Strike Common
Door Strike Normally Closed
Note: All zones are supervised.
Maximum zoneline impedence
100 Ohms. Ground fault detected at
1420 Ohms or less.
7000INT Series Installation and Programming Guide | Digital Monitoring Products, Inc.
Figure 3: Keypad Back Showing Wiring Assignments
s
s
NC
C
s
NO
WHT
GRN
s
s
Z4 -
Z4 +
Z3 -
s
Z3 +
Z2 -
Z2 +
s
Z1 -
Z1 +
BLK
s
GRN
YEL
RED
Black – Ground
Green – Receive Data
Yellow – Send Data
Red – Keypad Power
1K EOL
– Zone 4
Zones
1K EOL
– Zone 3
1 through 4
7073-WINT
Keypads
1K EOL
– Zone 2
1K EOL
– Zone 1
All Keypads
6
