INSTALL THE KEYPAD

1

REMOVE THE COVER

The keypad housing is made up of two parts: the cover,
which contains the circuit board and components, and
Cover
the base.
To separate the keypad cover from the base, insert a
flathead screwdriver into one of the slots on the bottom Base
of the keypad and gently lift the screwdriver upward.
Repeat with the other slot. Gently separate the cover
from the base and set the cover containing the keypad
components aside. See Figure 2.
Figure 2: Separate the
Keypad Housing
