3
WIRE FOR ACCESS CONTROL
Internal Access Control Reader
The 7063-WINT and 7073-WINT keypads provide a built-in proximity card reader that
is compatible with most standard 125 kHz proximity credentials. An external
13.56 MHz proximity reader can be connected and will be compatible with 13.56 MHz
proximity credentials. For a list of publicly supported card formats, see Public Card
Formats.
Note: Some proximity credentials are not compatible with DMP proximity
keypads. Test the intended proximity credentials with the application before
installation. DMP does not guarantee compatability with credentials not
purchased from DMP.
External Access Control Reader
To accept Wiegand data input from other external card readers, connect a 12 VDC
external reader to a 7073-WINT keypad. Connect the red and black power wires
from the reader to the power wires from the panel. These connect in parallel with the
keypad power wires. Connect the reader (Data 1) wire to the white wire on the 5–wire
keypad cable. Connect the reader (Data 0) wire to the green/white wire on the 5–wire
keypad cable. See Figure 4.
7
Digital Monitoring Products, Inc | 7000INT Series Installation and Programming Guide
