Holtek TinyPower HT69F40A Manual page 90

TinyPower
PHFS Register – HT69F50A
Bit 7
Name PHFS7
R/W R/W
P�R 1
PHFS7: Port H 7 Function Selection
Bit 7
0: I/O
1: SEG39
PHFS6: Port H 6 Function Selection
Bit 6
0: I/O
1: SEG38
PHFS5: Port H 5 Function Selection
Bit 5
0: I/O
1: SEG37
PHFS4: Port H 4 Function Selection
Bit 4
0: I/O
1: SEG36
PHFS3: Port H 3 Function Selection
Bit 3
0: I/O
1: SEG35
PHFS2: Port H 2 Function Selection
Bit 2
0: I/O
1: SEG34
PHFS1: Port H 1 Function Selection
Bit 1
0: I/O
1: SEG33
PHFS0: Port H 0 Function Selection
Bit 0
0: I/O
1: SEG32
SFS Register – HT69F30A
Bit 7
Name —
R/W —
P�R —
Bit 7 Unimplemented, read as "0"
SFS6: TCK1 Source Selection
Bit 6
0: PA2
1: PD2
SFS5: TCK0 Source Selection
Bit 5
0: PA2
1: PD1
SFS4: INT1 Source Selection
Bit 4
0: PA0
1: PD0
Bit 3~0 Unimplemented, read as "0"
Rev. 1.20
HT69F30A/HT69F40A/HT69F50A
I/O Flash 8-Bit MCU with LCD & EEPROM
TM
6 5 4
PHFS6 PHFS� PHFS4
R/W R/W R/W
1 1 1
6 5 4
SFS6 SFS� SFS4
R/W R/W R/W
0 0 0
90
3 2 1
PHFS3 PHFS2 PHFS1
R/W R/W R/W
1 1 1
3 2 1
— — —
— — —
— — —
��to�e� 0�� 201�
0
PHFS0
R/W
1
0
—
—
—
