Holtek TinyPower HT69F40A Manual page 162

TinyPower
MFI0 Register – HT69F40A/HT69F50A
Bit 7
Name T2AF
R/W R/W
P�R 0
T2AF: TM2 Comparator A match interrupt request flag
Bit 7
0: No request
1: Interrupt request
T2PF: TM2 Comparator P match interrupt request flag
Bit 6
0: No request
1: Interrupt request
T0AF: TM0 Comparator A match interrupt request flag
Bit 5
0: No request
1: Interrupt request
T0PF: TM0 Comparator P match interrupt request flag
Bit 4
0: No request
1: Interrupt request
T2AE: TM2 Comparator A match interrupt control
Bit 3
0: Disable
1: Enable
T2PE: TM2 Comparator P match interrupt control
Bit 2
0: Disable
1: Enable
T0AE: TM0 Comparator A match interrupt control
Bit 1
0: Disable
1: Enable
T0PE: TM0 Comparator P match interrupt control
Bit 0
0: Disable
1: Enable
MFI1 Register – HT69F30A
Bit 7
Name —
R/W —
P�R —
Bit 7~6 Unimplemented, read as "0"
Bit 5 T1AF: TM1 Comparator A match interrupt request flag
0: No request
1: Interrupt request
Bit 4 T1PF: TM1 Comparator P match interrupt request flag
0: No request
1: Interrupt request
Bit 3~2 Unimplemented, read as "0"
Bit 1 T1AE: TM1 Comparator A match interrupt control
0: Disable
1: Enable
Bit 0 T1PE: TM1 Comparator P match interrupt control
0: Disable
1: Enable
Rev. 1.20
HT69F30A/HT69F40A/HT69F50A
I/O Flash 8-Bit MCU with LCD & EEPROM
TM
6 5 4
T2PF T0AF T0PF
R/W R/W R/W
0 0 0
6 5 4
— T1AF T1PF
— R/W R/W
— 0 0
162
3 2 1
T2AE T2PE T0AE
R/W R/W R/W
0 0 0
3 2 1
— — T1AE
— — R/W
— — 0
��to�e� 0�� 201�
0
T0PE
R/W
0
0
T1PE
R/W
0
