LCD Waveform Timing Diagram
The accompanying timing diagrams depict the display driver signals generated by the
microcontroller for various values of duty and bias. The huge range of various permutations only
permits a few types to be displayed here.
D u r i n g R e s e t o r L C D F u n c t i o n i s s w i t c h e d o f f
L C D F u n c t i o n i n N o r m a l O p e r a t i o n M o d e
Rev. 1.20
C O M 0 , C O M 1 , C O M 2
A l l s e g m e n t o u t p u t s
C O M 0
C O M 1
C O M 2
A l l s e g m e n t s O F F
C O M 0 s e g m e n t s O N
C O M 1 s e g m e n t s O N
C O M 2 s e g m e n t s O N
C O M 0 , 1 s e g m e n t s O N
C O M 0 , 2 s e g m e n t s O N
C O M 1 , 2 s e g m e n t s O N
A l l s e g m e n t s O N
LCD Driver Output – Type A- 1/3 Duty, 1/2 Bias
