PDFS Register – HT69F30A
Bit 7
Name PDFS7
R/W R/W
P�R 1
PDFS7: Port D 7 Function Selection
Bit 7
0: I/O
1: SEG7
PDFS6: Port D 6 Function Selection
Bit 6
0: I/O
1: SEG6
PDFS5: Port D 5 Function Selection
Bit 5
0: I/O
1: SEG5
PDFS4: Port D 4 Function Selection
Bit 4
0: I/O
1: SEG4
PDFS3: Port D 3 Function Selection
Bit 3
0: I/O
1: SEG3
PDFS2: Port D 2 Function Selection
Bit 2
0: I/O
1: SEG2
PDFS1: Port D 1 Function Selection
Bit 1
0: I/O
1: SEG1
PDFS0: Port D 0 Function Selection
Bit 0
0: I/O
1: SEG0
Rev. 1.20
6 5 4
PDFS6 PDFS� PDFS4
R/W R/W R/W
1 1 1
��
3 2 1
PDFS3 PDFS2 PDFS1
R/W R/W R/W
1 1 1
��to�e� 0�� 201�
0
PDFS0
R/W
1
