Holtek TinyPower HT69F40A Manual page 80

TinyPower
HT69F50A
Register
Name
7
PAWU PAWU7
PAPU PAPU7
PA PA7
PAC PAC7
PBPU PBPU7
PB PB7
PBC PBC7
PCPU —
PC —
PCC —
PDPU PDPU7
PD PD7
PDC PDC7
PEPU PEPU7
PE PE7
PEC PEC7
PFPU PFPU7
PF PF7
PFC PFC7
PGPU PGPU7
PG PG7
PGC PGC7
PHPU PHPU7
PH PH7
PHC PHC7
PAWUn: PA wake-up function control
0: Disable
1: Enable
PAn/PBn/PCn/PDn/PEn/PFn/PGn/PHn: I/O Data bit
0: Data 0
1: Data 1
PACn/PBCn/PCCn/PDCn/PECn/PFCn/PGCn/PHCn: I/O type selection
0: Output
1: Input
PAPUn/PBPUn/PCPUn/PDPUn/PEPUn/PFPUn/PGPUn/PHPUn: Pull-high function control
0: Disable
1: Enable
Rev. 1.20
HT69F30A/HT69F40A/HT69F50A
I/O Flash 8-Bit MCU with LCD & EEPROM
TM
Bit
6 5 4
PAWU6 PAWU� PAWU4
PAPU6 PAPU� PAPU4
PA6 PA� PA4
PAC6 PAC� PAC4
PBPU6 PBPU� PBPU4
PB6 PB� PB4
PBC6 PBC� PBC4
PCPU6 PCPU� PCPU4
PC6 PC� PC4
PCC6 PCC4 PCC4
PDPU6 PDPU� PDPU4
PD6 PD� PD4
PDC6 PDC� PDC4
PEPU6 PEPU� PEPU4
PE6 PE� PE4
PEC6 PEC� PEC4
PFPU6 PFPU� PFPU4
PF6 PF� PF4
PFC6 PFC� PFC4
PGPU6 PGPU� PGPU4
PG6 PG� PG4
PGC6 PGC� PGC4
PHPU6 PHPU� PHPU4
PH6 PH� PH4
PHC6 PHC� PHC4
�0
3 2 1
PAWU3 PAWU2 PAWU1
PAPU3 PAPU2 PAPU1
PA3 PA2 PA1
PAC3 PAC2 PAC1
PBPU3 PBPU2 PBPU1
PB3 PB2 PB1
PBC3 PBC2 PBC1
PCPU3 PCPU2 PCPU1
PC3 PC2 PC1
PCC3 PCC2 PCC1
PDPU3 PDPU2 PDPU1
PD3 PD2 PD1
PDC3 PDC2 PDC1
PEPU3 PEPU2 PEPU1
PE3 PE2 PE1
PEC3 PEC2 PEC1
PFPU3 PFPU2 PFPU1
PF3 PF2 PF1
PFC3 PFC2 PFC1
PGPU3 PGPU2 PGPU1
PG3 PG2 PG1
PGC3 PGC2 PGC1
PHPU3 PHPU2 PHPU1
PH3 PH2 PH1
PHC3 PHC2 PHC1
"—" Unimplemented, read as "0"
