TinyPower
PFFS Register – HT69F30A/HT69F40A/HT69F50A
Bit 7
Name PFFS7
R/W R/W
P�R 1
PFFS7: Port F 7 Function Selection
Bit 7
0: I/O
1: SEG23
PFFS6: Port F 6 Function Selection
Bit 6
0: I/O
1: SEG22
PFFS5: Port F 5 Function Selection
Bit 5
0: I/O
1: SEG21
PFFS4: Port F 4 Function Selection
Bit 4
0: I/O
1: SEG20
PFFS3: Port F 3 Function Selection
Bit 3
0: I/O
1: SEG19
PFFS2: Port F 2 Function Selection
Bit 2
0: I/O
1: SEG18
PFFS1: Port F 1 Function Selection
Bit 1
0: I/O
1: SEG17
PFFS0: Port F 0 Function Selection
Bit 0
0: I/O
1: SEG16
Rev. 1.20
HT69F30A/HT69F40A/HT69F50A
I/O Flash 8-Bit MCU with LCD & EEPROM
TM
6 5 4
PFFS6 PFFS� PFFS4
R/W R/W R/W
1 1 1
��
3 2 1
PFFS3 PFFS2 PFFS1
R/W R/W R/W
1 1 1
��to�e� 0�� 201�
0
PFFS0
R/W
1
