4.7

Erasing Data from Memory

Erasing data from the instrument's memory can only be performed while
in the STANDBY mode.
There are two ways to erase the memory:
Erasing the Memory using the PRESS Button:
1. Press and hold the PRESS button. When the ERASE (RED) LED
lights up, release the button.
This will arm the instrument for an erase operation (when not in record
mode). While armed to erase memory, the RED LED will blink at a fast
rate for a period of five seconds.
2. Press the PRESS button for another 0.5 seconds to complete the
erase operation.
NOTE: If the button is not pressed within five seconds of arming, the erase
operation will automatically disarm and memory will be maintained. For
this reason, if you do not intend to erase memory, simply wait until the
RED LED stops blinking at the fast rate.
Erasing the Memory using the SLII Control Panel:
1. Connect the instrument to the computer, then open the SLII Control
Panel.
2. Select Erase Memory from the Instrument Menu.
3. A dialog box will appear asking to confirm the erasure of instrument
memory. Select Yes to confirm or No to cancel the operation.
NOTE: Clearing the memory will also clear any stored alarms.
4.8

Data Storage

The logger captures Trend measurements.
Input Channel: Source for the measurement channel of the instrument.
Measurement Channel: Measurement of input. This can be a simple
