ated with each LED is indicated with text to the right of each LED.
• Refer to § 4.1 for detailed descriptions of each LED.
3. Control Button (PRESS)
This button marked "PRESS" selects the mode of operation. Use this
button to start or stop recordings, erase the memory, clear alarms and
turn the instrument ON/OFF.
4. Female Type Mini-B USB Connector
This connector is located on the bottom of the instrument.
5. Reset Switch (not shown)
The RESET switch resets the CPU and is located under the top cover.
To access this switch remove the battery compartment cover, then
remove the four screws holding the two halves of the case together.
The reset switch is located on the exposed PCB near the inputs.
6. Flash Upgrade Switches (not shown)
These two switches (accessible from under the top cover), along with
the RESET button (and PC software), are used to recover from a failed
flash upgrade procedure.
WARNING: If the RESET button is pressed when the logger is recording, it
will stop recording and data in memory may be lost.
