AEMC Simple Logger II Series User Manual page 15

MODEL
ELECTRICAL
Channels
Input
Measurement Range
(3 ranges/channel)
Resolution
Accuracy
(50/60Hz)
Input Impedance
Sample Rate
Storage Rate
Storage Modes
Recording Length
Memory
Communication
Power Source**
Battery Life
MECHANICAL
Dimensions
Weight (with battery)
Case
Vibration
Shock
Drop
ENVIRONMENTAL
Operating Temperature
Storage Temperature
Relative Humidity
Altitude
SAFETY
Safety Rating
Environmental
Simple Logger II Series
®
One 4-position removable screw-type terminal block
Range 1: -100mV to 100mV
Range 2: -1V to 1V
Range 3: -10V to 10V
Range 1: 0.1mV
Range 2: 1mV
Range 3: 10mV
Range 1: ±(0.5% of Reading +1mV)
Range 2: ±(0.5% of Reading +1mV)
Range 3: ±(0.5% of Reading +10mV)
100mV/1V: 80K; 10V: 800K
Maximum of 8 samples taken at storage interval
Programmable from 125mS to 1 day
Start/Stop, FIFO and Extended Recording Mode* (XRM
15 minutes to 8 weeks, programmable using DataView
240,000 measurement (512KB).
Recorded data is stored in non-volatile memory and
retained even if battery is low or removed.
USB 2.0 optically isolated
2x1.5V AA (LR6) alkaline batteries
100 hrs to >45 days
(dependent on storage rate/recording length)
5.45 x 2.75 x 1.28" (136 x 70 x 32mm)
IEC 68-2-6 (1.5mm, 10 to 55Hz)
IEC 68-2-27 (30G)
14° to 122°F (-10° to 50°C)
-4° to 140°F (-20° to 60°C)
Up to 85% @ 95°F (35°C), Non-condensing
EN 61010-1; 50V Cat. III; Pollution Degree 2
L432
Two
DC
DC
DC
6.4 oz (181g)
UL94-V0
IEC 68-2-32 (1m)
2000m
IP40
)
™
®
13
