Use only factory specified replacement parts. AEMC
responsible for any accident, incident, or malfunction following a repair
done other than by its service center or by an approved repair center.
5.1

Changing the Batteries

WARNING: Turn the unit off before changing the batteries or loss of
recorded data may occur. Disconnect the unit from any voltage measure-
ment points before opening the rear cover to change the batteries.
• Remove the screw from the battery cover
• Slide off cover to remove
• Replace with only 1.5V AA (LR6) alkaline batteries, then replace
cover
• Press the
NOTE: If the instrument is stored without the batteries installed, the
internal clock will need to be reset using the Simple Logger
Panel software once the batteries are installed. Only store the unit with the
batteries installed for short periods of time. For prolonged storage of the
unit, it is recommended to remove the batteries.
An additional memory backup capacitor is used to provide backup power
while the main batteries are being changed. This backup power will last for
approximately 10 seconds while batteries are not installed.
5.2

Cleaning

WARNING: Disconnect all inputs before cleaning.
The body of the logger should be cleaned with a cloth moistened with
soapy water. Rinse with a cloth moistened with clean water. Do not sub-
merge the logger in water. Do not use solvent.
Simple Logger II Series
®
CHAPTER 5

MAINTENANCE

PRESS button for 2 seconds to turn ON
will not be held
®
II Control
®
