AEMC Simple Logger II Series User Manual page 26

Event: Recording with a Partial or Full Memory
If the RED LED is double-blinking, the memory must be erased before any
further recording can be performed.
If the RED LED is single-blinking prior to starting a New Recording Ses-
sion, the memory is partially full.
To save, clear or check memory availability, use the Simple Logger
Control Panel software.
There may be instances where the GREEN LED is also double-blinking
indicating that the logger is still recording. The user can choose to stop the
Recording Session and download the session and/or erase the memory.
NOTE: The logger memory cannot be erased while in the Record mode.
The recording must be stopped first.
Event: Memory Filled During Recording Session (Start/Stop Mode)
If the logger is recording using the Start/Stop mode and memory is filled
before the Recording Session has finished, the session will end.
The following happens:
• The GREEN LED single-blinks.
• The RED LED double-blinks.
At this time:
• The memory can be downloaded and erased.
• A new recording can be started or scheduled once memory is erased.
NOTE: If in either the XRM or FIFO mode, the recording will continue even after
memory becomes full. Memory will be freed to make room for new samples.
The method of freeing memory will depend on the recording mode.
Event: Battery Power is Insufficient for a Full Recording Duration
If the battery voltage drops below 1.7V, the following will occur:
• The Recording Session will terminate.
• The Data will be saved.
• The GREEN and RED LED will turn OFF.
The logger continues to record until the battery voltage drops below 1.7V.
Pressing the PRESS button may not turn the unit ON at all. The battery
