The instrument contains protection circuitry to prevent it from being turned
on when the battery voltage is below 1.7V.
There are two thresholds for the battery voltage:
• The first is used to indicate low battery. The low battery indicator will
blink when the battery voltage drops below 1.8V.
• The second is used to determine when to terminate recording and
turn the unit off. The shutdown threshold is when the battery voltage
drops below 1.7V.
4.4

Recording Data

NOTE: The Simple Logger
to fit the users needs (see the Configuring the Simple Logger
inside the DataView
Once a configuration is written to the instrument, the logger will no longer
need to be connected to DataView
When data is stored in the memory, the user may download the informa-
tion onto a hard-disk (see the Downloading Recorded Instrument Data
section inside the DataView
NOTE: A scheduled recording will still start even if the Simple Logger
is turned off.
4.4.1

Starting a Recording Session

NOTE: A new recording cannot be started if the memory is full.
1. Connect the instrument to the measurement source.
2. Make sure the logger is in STANDBY mode (see § 4.3).
3. Press and hold the PRESS button. When the START (GREEN) LED
lights up, release the button.
4. The GREEN LED double-blinks when the logger is recording.
20
II is factory configured and may be altered
®
user manual).
®
to start the scheduled recording.
®
user manual).
®
II section
®
®
Simple Logger II Series
®
II
