4.4

Downloading Recorded Data

Recorded measurements stored in the instrument are transferred to a
computer via the DataView Simple Logger II Control Panel, as described
in the Help system that comes with the program.
4.5

Clearing Alarm Indication

Clearing alarms can be performed in the STANDBY or RECORD mode.
1. Press and hold the PRESS button. When the ALARM (YELLOW) LED
lights up, release the button. The YELLOW LED will blink at a fast rate
for a period of five seconds.
2. Press the PRESS button for another 0.5 second to complete the oper-
ation.
This does not clear any stored alarms, only indications. Stored alarms can
only be cleared when memory is erased (see § 4.6).
4.6

Erasing Data from Memory

Erasing data from the instrument's memory can only be performed while
in the STANDBY mode.
There are two ways to erase the memory:
Erasing the Memory using the PRESS Button:
1. Press and hold the PRESS button. When the ERASE (RED) LED
lights up, release the button.
This will arm the instrument for an erase operation (when not in record
mode). While armed to erase memory, the RED LED will blink at a fast
rate for a period of five seconds.
2. Press the PRESS button for another 0.5 second to start the erase
operation. During the erase operation the LED will blink once every
second. Erasure takes about 20 seconds to complete.
