AEMC Simple Logger II Series User Manual page 17

MODEL
ELECTRICAL
Channels
Input
Measurement Type:
Resolution
Accuracy (J, K, T, N, E)
Accuracy (R, S)
Temperature
Coefficient:
Maximum Differential
Voltage
Sample Rate
Storage Rate
Storage Modes
Recording Length
Memory
Communication
Power Source**
Battery Life
MECHANICAL
Dimensions
Weight (with battery)
Case
Vibration
Shock
Drop
ENVIRONMENTAL
Operating Temperature
Storage Temperature
Relative Humidity
Altitude
SAFETY
Safety Rating
Simple Logger II Series
®
Two miniature thermocouple connectors
J
-346 to +2192
K
-328 to +2501
T
-418 to +752
N
-328 to +2372
E
-238 to 1742
R
32 to 3212
S
32 to 3212
±(0.2% of Reading + 0.6° C) ≤ (-100° C)
±(0.15% of Reading + 0.6°C) > (-100° C), ≤ (+100°C)
±(0.1% of Reading + 0.6°C) > (+100°C)
±(0.15% of Reading + 1.0°C) (0° to +100°C)
±(0.1% of Reading + 1.0°C) > (+100°C)
or ± (0.02% of Reading + 0.03°F) / °F between operating
temperature of -10°C to +18°C and +28°C to +50°C
Maximum of 8 samples taken at storage interval
Start/Stop, FIFO and Extended Recording Mode* (XRM
15 minutes to 8 weeks, programmable using DataView
240,000 measurement (512KB). Recorded data is stored in non-
volatile memory and retained even if battery is low or removed.
100 hrs to > 45 days (dependent on storage rate/recording length)
4.94 x 2.75 x 1.28" (125 x 70 x 32mm)
Up to 85% @ 95°F (35°C), Non-condensing
EN61010-1; 50V Cat. III; Pollution Degree 2
L642
Two
°F
° °
0.1 C/F < 1000 C/F; 1
± (0.02% of Reading + 0.03°C)/ °C
1V
(between T1 and T2)
Programmable from 5 sec to 1 day
USB 2.0 optically isolated
2x1.5V AA (LR6) alkaline batteries
7 oz (200g)
UL94-V0
IEC 68-2-6 (1.5mm, 10 to 55Hz)
IEC 68-2-27 (30G)
IEC 68-2-32 (1m)
14° to 122°F (-10° to 50°C)
-4° to 140°F (-20° to 60°C)
2000m
°C
-210 to +1200
-200 to +1372
-250 to +400
-200 to +1300
-150 to +950
0 to 1767
0 to 1767
° °
≥ 1000
C/F
)
™
®
15
