voltage may rise slightly after the unit turns itself off. In this event, the unit

may turn on momentarily as a result of a button press.

The batteries must be replaced before the recorded session(s) can be

downloaded from the instrument.

NOTE: Replacing the batteries while the unit is OFF will not result in the

loss of data memory. The internal backup capacitor will maintain the clock

and memory while the main batteries are being replaced. If the battery

level falls below the usable level or if the batteries have been removed

for an extended period of time, the clock time will be lost. However, the

recorded memory will be maintained since it is stored in Flash memory.

Event: Recording Session has Ended

The logger will be in STANDBY mode if one of the following occurs:

•

The session terminates due to recording end time being reached.

•

The recording in START/STOP mode fills the memory.

•

The user terminates the session by pressing the

until the STOP (ORANGE) LED lights up and releasing the button

before the next LED lights, or issues a Stop Recording command

from the Simple Logger

Under these conditions, it is possible to turn the logger ON from the

computer to download the data, if the batteries have sufficient power.

The logger is now ready for a New Session or Download. Pressing the

PRESS button until the START (GREEN) LED lights up and releasing the

button before the next LED lights, will start a New Session depending on

the available memory.
