CHAPTER 4

OPERATION

4.1

The ON/OFF state of the instrument can be determined by pressing the

PRESS button for less than 0.5 seconds. If the instrument is ON, the status

of the instrument will be shown by the LEDs. If the instrument is OFF no

indication will be given (the LEDs will not blink).

The instrument is turned ON by pressing the PRESS button until all LEDs

light. At this point, the button can be released and the instrument will

remain in the ON state. If the button is released before all the LEDs light

(in unison), the instrument will remain in the OFF state.

When holding the PRESS button while the instrument is ON, each LED

will light in sequence. Continuing to hold the PRESS button until the last

LED lights, turns the instrument OFF. At this point, releasing the button will

result in no action being taken. This provides a mechanism to cancel (or

ignore) the button press.

Control of the instrument is performed by pressing and holding the PRESS

button (while the instrument is ON) until the control LED corresponding

to the desired operation lights. Releasing the button when the desired

control LED is illuminated results in the corresponding operation being

performed.

Turning the instrument OFF (pressing and holding the PRESS button until

the Blue LED lights), will not terminate an active recording or prevent a

scheduled recording from starting.

While the instrument is OFF, it will turn ON for each scheduled recording.
