Introduction

WARNING
AVERTISSEMENT :
•
•
•
•
•
•
This section gives an overview of this guide and the DMS 1600,
DMS 2000, DMS 3200, and DMS 3600 and describes their features.
Topics that are covered include:
•

About this Guide

•
About the DMS Matrix Switchers
About this Guide
NOTES:
•
•
This setup guide helps to easily and quickly set up and configure an
Extron DMS matrix switcher. Step by step instructions show how to:
•
Install the input and output boards
•
Connect the hardware
•
Perform basic operations
•
Use both the
Instruction Set (SIS) commands
•
Load and start the Matrix Switchers Control Program
•
Connect to the built-in HTML pages
•
Reconfigure
supplies, and fans
:
The DMS fiber optic I/O boards output continuous invisible
light, which may be harmful to the eyes; use with caution.
Les cartes d'E/S fibre optique DMS émettent une lumière
invisible continue, qui peut être dangereuse pour les yeux ; à
utiliser avec précaution.
Do not look into the fiber optic cable connectors or into the
fiber optic cables themselves.
Ne pas fixer directement les connecteurs optiques ou les
câbles fibre optique.
Plug the attached dust caps into the optical transceivers when
the fiber cable is unplugged.
Associez les bouchons anti-poussière à l'ensemble émetteur/
récepteur optique lorsque le câble fibre optique est débranché
For more information on any subject in this guide, see
the DMS Series Matrix Switcher User Guide, available at
www.extron.com.
Throughout this guide, all of the covered switchers are referred
to as "DMS matrix switchers" unless a significant difference is
noted in their features or operation.
front panel controls
the switcher by adding or removing boards, power
DMS 1600, DMS 2000, DMS 3200, DMS 3600 • Introduction
