Panel Information Dialog
Displays in response to the Panel Information command.
This dialog displays a summary of panel and the configurator information, with options to view
more detail. The information includes:
• The Product Version
• Name and Version of the job currently loaded on the panel.
• Model (deduced from Product, System (build) Type and Hardware Features).
• The Date it was sent
• The ESD and Tech who sent / owns the job. (For products secured with a key)
• Security Key SIN. (For products secured with a key)
• FXConfig Version
• Date and Time Last Changed
• Number of times auto config'd.
• The Panel Time.
An Advanced button launches Advanced Panel Info which retrieves and displays the Type,
Product Version, Language, on line status, etc. of all Nodes and their CPUS.
An Update button allows the panel time to be corrected/updated from the configurator for
those products that support the feature.
