14.2 Paging and Fire Fighter Telephone Modules

These modules can be installed on the door or inside any node with paging module slots. The
specific number and combination of paging and fire fighter telephone modules varies
depending on the application and requirements of the job.
Paging and FireFighter Telephone Modules
QMT-5302NV
Vertical Network
Telephone Control Unit

14.3 Adder Modules

These modules can be installed inside any node with adder module slots. The specific number
and combination of adder modules varies depending on the application and requirements of
the job.
Adder Modules
ALCN-792M
Quad Loop Adder
Motherboard*
DM-1008A
Eight Initiating
Circuit Module
PR-300A
Polarity Reversal/City Tie Module
(Mounts above the ribbon cable on the Main Board)
QMP-5101NV
Vertical Network
Paging Control Unit
ALCN-792D
Quad Loop Adder
Daughter Board*
SGM-1004A
Four Indicating
Circuit Module
Each of these Adder modules occupy one module
slot and mount inside the following chassis unless
otherwise specified:
FX-2003-12N Compact Main Chassis
FX-2017-12N Mid-Size Main Chassis
FX-2009- 12N Large Main Chassis
ECX-0012 Expander Chassis.for FX-2009-12
QMP-5101N
Network Paging
Control Unit
QMT-5302N
Network Telephone
Control Unit
FNC-2000
Network Interface
Controller Module
RM-1008A
Eight Relay
Circuit Module
Hardware Layouts
QAZT-5302
Addressable Telephone
Selector Module
FOM-2000-SP
Single Port Digital
Network Fiber
Optic Module
UDACT-300A
Digital Alarm
Communicator
Module
* The ALCN-792D
mounts directly onto
the ALCN-792M
