Standard Audio Example
This example plays an initial Your attention please two times. This is followed by a message
instructing occupants not to use the elevator, played only once. The entire sequence is
repeated 5 times.
Command Count
Audio Data 2
Audio Data 1
Repeat All 5
Composition
Commands in the Composition list view can be added, deleted and moved up and down.
Select a WAV file in the Audio Clips pane and press the >> button to move it into the message.
Select a Loop Command and press the >> button to move it into the message. Loops can be
nested up to four deep. A Loop 1 command specifies an outer-most loop, etc.
Commands in the Composition list view have the following columns.
Clip
Your Attention
Dont Use Elevator
-
