Loop Detail
The list view displays the hard wired (Conventional) circuits or addressable devices of a Loop,
when that loop is selected in the tree. The same view is also used for an audio controller's
loops: phone and voice lines (inputs) and amplifiers (outputs). The base set of columns is the
same for all, but there are some Product and Loop Type dependencies.
Some columns containing advanced or internal information are normally hidden. They are
listed as Visible / No in the following table. Other columns are conditionally visible.
Name
Addr
Lp
Lp Addr
Ckt No
Device
Type
Code
Sens Lvl Pre
Sens
Sens Lvl 2
Sens Lvl 3
Sens B Lvl
Pre
110
Visible Description
For regular addressable devices, the displayed address is
Yes the same as device address. For conventional circuits
display adder & circuit on adder.
No Loop Number
For conventional, its relative position on the loop. For
No
addressable, the actual address setting.
An internal, sequentially assigned number. One set for
No
inputs, another for outputs.
Conventional - fixed, depending on the circuit adder. See
Add Circuit Adders.
Addressable - chosen when Adding Device(s). Can be
edited conditionally. For example, a Photo Detector can be
Yes
changed to other types of detector, a Relay Opt module
can be changed to a Supv. Opt module. Other changes
can only be achieved by deleting the device and adding
another.
The process Type of the Device. Can be edited (combo
box). The list of Types shown in the combo box will
Yes
depend on the Device. E.g. Device Relay Opt Module can
be assigned Relay, Signal or Strobe.
No Applies only to input zones.
On Addressable The Pre-alarm (or for some device types the trouble)
Loops. sensitivity level. Optional.
The alarm level 1 sensitivity of the sensor. Displays a
On Addressable
combo with sensitivity in appropriate units for the device
Loops.
type. Required for sensors.
The alarm level 2 sensitivity of the sensor. Displays a
On Addressable
combo with sensitivity in appropriate units for the device
Loops.
type. Optional.
The alarm level 3 sensitivity of the sensor. Displays a
On Addressable
combo with sensitivity in appropriate units for the device
Loops.
type. Optional if Lvl2 specified.
On Addressable
The after hours and night time Pre-alarm (or for some
Loops, if after
device types the trouble) sensitivity level. Optional.
hours specified.
