Audible and Visual Alarm Indicators

When an alarm condition occurs:
•
The alarm LED indicator on the Alarm Indicator/Audio
Pause button lights
•
The audible alarm sounds
•
A message appears on the screen describing the type of
alarm
•
The remote alarm (if applicable) is activated
Each of these is described in detail below.

Alarm LED Indicators

The Alarm Indicator/Audio Pause button on the front of the ventilator
lights up as follows whenever an alarm is detected:
•
Red Flashing Indicator – When the device detects a high
priority alarm, the Alarm Indicator/Audio Pause button
flashes red.
•
Yellow Flashing Indicator – When the device detects a
medium priority alarm, the Alarm Indicator/Audio Pause
button flashes yellow.
•
Yellow Solid Indicator – When the device detects a low
priority alarm, a solid yellow light appears on the Alarm
Indicator/Audio Pause button.
The Alarm Indicator/Audio Pause button does not light up when
informational messages or confirmation alerts display.
Trilogy100 clinical manual
Alarm Indicator/Audio Pause
Button
