www.philips.com/healthcare
healthcare@philips.com
Asia
+49 7031 463 2254
Europe, Middle East, Africa
+49 7031 463 2254
Latin America
+55 11 2125 0744
North America
+1 425 487 7000
800 285 5585 (toll free, US only
This guide contains abstracted information from the User Manual; please refer
to the latest version for complete information regarding the BiPAP A40 device.
© 2016 Koninklijke Philips N.V. All rights are reserved.
BiPAP A40 is registered trademark of Philips.
Philips Healthcare reserves the right to make changes in specifications and/or to
discontinue any product at any time without notice or obligation and will not be
liable for any consequences resulting from the use of this publication.
Broudy RP 4/24/16 MCI 4107145 PN 1098001
Philips Respironics
1010 Murry Ridge Lane
Murrysville, PA 15668 USA
Philips Respironics Asia Pacific
+65 6882 5282
Philips Respironics Australia
+61 (2) 9947 0440
1300 766 488 (toll free,
Australia only)
Philips Respironics China
+86 400 828 6665
+86 800 828 6665
)
Philips Respironics Deutschland
+49 8152 93 06 0
Philips Respironics France
+33 2 51 89 36 00
Philips Respironics Italy
+39 039 203 1
Philips Respironics Sweden
+46 8 120 45 900
Philips Respironics Switzerland
+41 6 27 45 17 50
Philips Respironics
United Kingdom
+44 800 1300 845
www.philips.com/respironics
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for PHILIPS Respironics BiPAP A40
Summary of Contents for PHILIPS Respironics BiPAP A40
- Page 1 +49 8152 93 06 0 This guide contains abstracted information from the User Manual; please refer to the latest version for complete information regarding the BiPAP A40 device. © 2016 Koninklijke Philips N.V. All rights are reserved. BiPAP A40 is registered trademark of Philips.
-
Page 2: Battery Module
Battery module To connect the battery module to the BiPAP A40 device and install the detachable battery, complete the following steps: 1. Remove the side cover on the therapy device 2. Line up the detachable battery module and the therapy device side by side 3. - Page 3 DC power inlet AC power inlet Filter area To connect the oximetry module: Remove the cover from the accessory slot on the back of the BiPAP A40 Remove the cover from the oximetry accessory Plug the oximetry accessory into the accessory slot...
- Page 4 Guidelines for ventilation se Initial IPAP = 8 - 10 cmH O, EPAP = 4 cmH O and RR = 10 - 12 BPM settings IPAP Increase IPAP if the patient wants more air, targeting patient tidal volume at 8 ml/kg of ideal weight EPAP •...
- Page 5 n set-up Conversion table to set the inspiratory time for controlled breaths Set back up breath rate I/E 1/3, I/E 1/2, I/E 1/1, (BPM) Ti/Ttot 25% Ti/Ttot 33% Ti/Ttot 50% 1.5 s 2.0 s 3.0 s 1.4 s 1.8 s 2.7 s 1.3 s 1.7 s...
- Page 6 BiPAP A40 Set-up guide Getting started Humidification Connection to oximetry Main screen Menus Guidelines for ventilation set-up Battery module...
-
Page 7: Getting Started
Getting started Device navigation How to start therapy S/T AVAPS: 0.5 S/T AVAPS: 0.5 Setup 12/30/2010 12/30/2010 06:12 PM 06:12 PM Menu Therapy Humidifier Ramp Menu • Connect the Display screen device to AC Perform action specified on-screen or DC power (humidifier setting, cancel action source, or use detachable... -
Page 8: How To Unlock
How to stop therapy How to unlock S/T AVAPS: 5.0 Pressure Leak Pressure Leak 12.6 l/min l/min MinVent I:E Ratio 1:1.0 l/min Standby Power Off Cancel Navigate Menu • Press To unlock the device • Press and hold • To keep power on but stop for a few seconds to access therapy, select ‘Standby’... -
Page 9: Main Screen
Main screen Mode of ventilation AVAPS activated with a speed rate of 0.5cmH O/min. S/T AVAPS: 0.5 Breath Pressure bar graph indicator (patient or Pressure Leak machine settable 12.1 30.0 l/min Real-time in Options) I:E Ratio MinVent monitored values 1:3.0 l/min when detailed view ON... - Page 10 Menus Menu: Settings and alarms Mode CPAP, S, S/T, PC, T, AVAPS-AE Trigger type Auto-Trak/Flow Trigger/ Auto-Trak (sensitive) Flex Lock (only in S mode) On (locked)/Off (unlocked) Flex (only in S mode) On/Off AVAPS On/Off AVAPS rate 0.5 - 5 cmH O/min, in 0.5 cmH O/min increments Tidal volume...
- Page 11 Menu: Settings and alarms (cont.) Tubing type lock On (locked)/Off (unlocked) Tubing type 15 mm/22 mm System One resistance lock On (locked)/Off (unlocked) System One resistance (interface type) 0, X1, X2, X3, X4, X5 or Invasive Circuit disconnect alarm Off; 15 or 60 sec Apnea alarm Off;...
- Page 12 Menu: Options To navigate through the Options S/T AVAPS: 0.6 menu: Setup • Use to scroll Menu Options 1/18 through the menu. Menu access Full Detailed view Language English Pressure units • Use the left and right Breath Indicator Patient Finish Modify Navigate...
