Basic Operating Principles ...
LCP Keys
[Hand On]
[Hand On]⇒(Off)
[Auto On]
[Auto On]⇒(Off)
All keys
All keys
Table 11.1 Local and Remote Reference Configurations
11.2.2 Remote Handling of References
Remote handling of reference applies to both open-loop
and closed-loop operation. See Illustration 11.3.
Up to 8 internal preset references can be programmed into
the drive. The active internal preset reference can be
selected externally through digital control inputs or
through the serial communications bus.
External references can also be supplied to the drive, most
commonly through an analog control input. All reference
11 11
100
VLT® AQUA Drive FC 202
Parameter 3-13 Reference Active
Site Reference
Linked to hand/auto Local
Linked to hand/auto Local
Linked to hand/auto Remote
Linked to hand/auto Remote
Local Local
Remote Remote
Danfoss A/S © 05/2017 All rights reserved.
sources and the bus reference are added to produce the
total external reference. The active reference can be
selected from the following:
•
External reference
•
Preset reference
•
Setpoint
•
Sum of the external reference, preset reference,
and setpoint
The active reference can be scaled. The scaled reference is
calculated as follows:
Y
Reference = X + X ×
100
Where X is the external reference, the preset reference, or
the sum of these references, and Y is parameter 3-14 Preset
Relative Reference in [%].
If Y, parameter 3-14 Preset Relative Reference, is set to 0%,
the scaling does not affect the reference.
