Danfoss VLT AQUA Drive FC 202 Design Manual page 37

Specifications
VLT® AQUA Drive FC 202
High/normal load
(High overload=150% current during 60 s, normal
overload=110% current during 60 s)
Typical shaft output at 550 V [kW]
Typical shaft output at 575 V [hp]
Typical shaft output at 690 V [kW]
Enclosure size
Output current (3-phase)
Continuous (at 550 V) [A]
Intermittent (60 s overload) (at 550 V) [A]
Continuous (at 575/690 V) [A]
Intermittent (60 s overload) (at 575/690 V) [A]
Continuous kVA (at 550 V) [kVA]
Continuous kVA (at 575 V) [kVA]
Continuous kVA (at 690 V) [kVA]
Maximum input current
Continuous (at 550 V) [A]
Continuous (at 575 V) [A]
Continuous (at 690 V) [A]
Maximum number and size of cables
per phase (E1h)
- Mains and motor without brake [mm
- Mains and motor with brake [mm
- Brake or regeneration [mm 2 (AWG)
Maximum number and size of cables
per phase (E3h)
- Mains and motor without brake [mm
- Mains and motor with brake [mm
- Load share or regeneration [mm
Maximum external mains fuses [A]
Estimated power loss at 600 V [W]
Estimated power loss at 690 V [W]
Efficiency 4)
Output frequency [Hz]
Heat sink overtemperature trip [°C (°F)]
Control card overtemperature trip [°C (°F)]
Power card overtemperature trip [°C (°F)]
Fan power card overtemperature trip [°C (°F)]
Active in-rush card overtemperature trip [°C (°F)]
Table 7.4 Technical Specifications, Mains Supply 3x525–690 V AC
MG22B102
Design Guide
2 1)
(AWG)]
2 (AWG) 1)
1)
2 (AWG)] 1)
2 1)
(AWG)
2 1)
(AWG)
2)
3) 4)
3) 4)
Danfoss A/S © 05/2017 All rights reserved.
N560
HO NO
400 450
500 600
500 560
E1h/E3h
523 596
785 656
500 570
750 627
498 568
498 568
598 681
504 574
482 549
482 549
5x240 (5x500 mcm)
4x240 (4x500 mcm)
2x185 (2x350 mcm)
6x240 (6x500 mcm)
2x185 (2x350 mcm)
4x185 (4x350 mcm)
800
6833 8076
6678 7852
0.98
0–590
110 (230)
80 (176)
85 (185)
85 (185)
85 (185)
N630
HO NO
450 500
600 650
560 630
E1h/E3h
596 630
894 693
570 630
855 693
568 600
568 627
681 753
574 607
549 607
549 607
5x240 (5x500 mcm)
4x240 (4x500 mcm)
2x185 (2x350 mcm)
6x240 (6x500 mcm)
2x185 (2x350 mcm)
4x185 (4x350 mcm)
800
8069 9208
7848 8921
0.98
0–590
110 (230)
80 (176)
85 (185)
85 (185)
85 (185)
