Exterior and Terminal Dimen...
8
8
1
1
Heat sink access panel (optional)
Illustration 8.15 Back View of E3h
56
VLT® AQUA Drive FC 202
412
(16.2)
206
48 (1.9)
(8.1)
154 (6.1)
744 (29.3)
39 (1.5)
215 (8.5)
430 (16.9)
4X 457 (18.0)
22 (0.9)
464 (18.3)
Danfoss A/S © 05/2017 All rights reserved.
18 (0.7)
168 (6.6)
1335 (52.5)
168 (6.6)
136 (5.4)
MG22B102
