10.4.2 Control Terminals
Illustration 10.5 shows the removable drive connectors.
Terminal functions and default settings are summarized in
Table 10.5 – Table 10.7.
Illustration 10.5 Control Terminal Locations
1
61 68 69 39 42 50 53 54 55
2
12 13 18 19 27 29 32 33 20 37
1 Serial communication terminals
2 Digital input/output terminals
3 Analog input/output terminals
Illustration 10.6 Terminal Numbers Located on the Connectors
MG22B102
Design Guide
Terminal
61
68 (+)
69 (-)
01, 02, 03
04, 05, 06
Table 10.5 Serial Communication Terminal Descriptions
3
Terminal
12, 13
18
19
32
33
Danfoss A/S © 05/2017 All rights reserved.
Serial communication terminals
Parameter Default
setting
– – Integrated RC-filter for
cable shield. ONLY for
connecting the shield
in case of EMC
problems.
Parameter – RS485 interface. A
group 8-3* FC switch (BUS TER.) is
Port Settings provided on the
control card for bus
Parameter –
termination
group 8-3* FC
resistance. See the
Port Settings
VLT
202 110–1400 kW
Design Guide.
Relays
Parameter 5-40 [0] No Form C relay output.
Function Relay operation For AC or DC voltage
[0] and resistive or
inductive loads.
Parameter 5-40 [0] No
Function Relay operation
[1]
Digital input/output terminals
Parameter Default
setting
– +24 V DC 24 V DC supply
voltage for digital
inputs and external
transducers.
Maximum output
current 200 mA for all
24 V loads.
Parameter 5-10 [8] Start Digital inputs.
Terminal 18
Digital Input
Parameter 5-11 [10]
Terminal 19 Reversing
Digital Input
Parameter 5-14 [0] No
Terminal 32 operation
Digital Input
Parameter 5-15 [0] No
Terminal 33 operation
Digital Input
Description
®
AQUA Drive FC
10 10
Description
77
