Danfoss VLT AQUA Drive FC 202 Design Manual page 35

Specifications
VLT® AQUA Drive FC 202
High/normal load
(High overload=150% current during 60 s, normal overload=110%
current during 60 s)
Typical shaft output at 400 V [kW]
Typical shaft output at 460 V [hp]
Enclosure size
Output current (3-phase)
Continuous (at 400 V) [A]
Intermittent (60 s overload)
(at 400 V) [A]
Continuous (at 460/500 V) [A]
Intermittent (60 s overload)
(at 460/500 V) [A]
Continuous kVA (at 400 V) [kVA]
Continuous kVA (at 460 V) [kVA]
Maximum input current
Continuous (at 400 V) [A]
Continuous (at 460/500 V) [A]
Maximum number and size of cables
per phase (E2h)
- Mains and motor without brake [mm
- Mains and motor with brake [mm
2
- Brake or regeneration [mm (AWG)
Maximum number and size of cables
per phase (E4h)
- Mains and motor without brake [mm
- Mains and motor with brake [mm
- Load share or regeneration [mm
Maximum external mains fuses [A]
Estimated power loss at 400 V [W]
Estimated power loss at 460 V [W]
4)
Efficiency
Output frequency [Hz]
Heat sink overtemperature trip [°C (°F)]
Control card overtemperature trip [°C (°F)]
Power card overtemperature trip [°C (°F)]
Fan power card overtemperature trip [°C (°F)]
Active in-rush card overtemperature trip [°C (°F)]
Table 7.2 Technical Specifications, Mains Supply 3x380–480 V AC
1) American Wire Gauge.
2) For fuse ratings, see chapter 10.5 Fuses and Circuit Breakers.
3) Typical power loss is at normal conditions and expected to be within
values are based on a typical motor efficiency (IE/IE3 border line). Lower efficiency motors add to the power loss in the drive. Applies for
dimensioning of drive cooling. If the switching frequency is higher than the default setting, the power losses can increase. LCP and typical control
card power consumptions are included. For power loss data according to EN 50598-2, refer to www.danfoss.com/vltenergyefficiency. Options and
customer load can add up to 30 W to the losses, though usually a fully loaded control card and options for slots A and B each add only 4 W.
4) Measured using 5 m (16.4 ft) shielded motor cables at rated load and rated frequency. Efficiency measured at nominal current. For energy
efficiency class, see chapter 7.5 Ambient Conditions. For part load losses, see www.danfoss.com/vltenergyefficiency.
MG22B102
Design Guide
2 (AWG)] 1)
2 1)
(AWG)
1)
2 1)
(AWG)]
2 (AWG) 1)
2 1)
(AWG)
2)
3) 4)
3) 4)
Danfoss A/S © 05/2017 All rights reserved.
N500
HO NO
450 500
600 650
E2h/E4h
800 880
1200 968
730 780
1095 858
554 610
582 621
771 848
704 752
6x240 (6x500 mcm)
5x240 (5x500 mcm)
2x185 (2x350 mcm)
6x240 (6x500 mcm)
2x185 (2x350 mcm)
4x185 (4x350 mcm)
1200
8352 9473
7182 7809
0.98
0–590
110 (230)
80 (176)
85 (185)
85 (185)
85 (185)
± 15% (tolerance relates to variety in voltage and cable conditions.) These
N560
HO NO
500 560
650 750
E2h/E4h
880 990
1320 1089
780 890
1170 979
610 686
621 709
848 954
752 858
6x240 (6x500 mcm)
5x240 (5x500 mcm)
2x185 (2x350 mcm)
6x240 (6x500 mcm)
2x185 (2x350 mcm)
4x185 (4x350 mcm)
1200
9449 11102
7771 9236
0.98
0–590
100 (212)
80 (176)
85 (185)
85 (185)
85 (185)
33
7 7
