Application Examples
NOTICE
Set the analog input 2, (terminal 54) format to mA.
(switch 202).
Parameter settings
Parameter
Parameter 1-20 Motor Power [kW]/parameter 1-21 Motor Power
[HP]
Parameter 1-22 Motor Voltage
Parameter 1-24 Motor Current
Parameter 1-28 Motor Rotation Check
Enable reduced automatic motor adaptation in
parameter 1-29 Automatic Motor Adaptation (AMA)
Table 12.14 Relevant Parameters for Submersible Pump
Application
Parameter
Parameter 3-02 Minimum
Reference
Parameter 3-03 Maximum
Reference
Parameter 3-84 Initial Ramp Time (2 s)
Parameter 3-88 Final Ramp Time
Parameter 3-41 Ramp 1 Ramp Up
Time
Parameter 3-42 Ramp 1 Ramp
Down Time
12 12
Parameter 4-11 Motor Speed Low
Limit [RPM]
Parameter 4-13 Motor Speed High
Limit [RPM]
Use the Closed-loop wizard under Quick Menu
set up the feedback settings in the PID controller.
Table 12.15 Example of Settings for Submersible Pump
Application
Parameter
Parameter 29-00 Pipe Fill Enable
Parameter 29-04 Pipe Fill Rate
Parameter 29-05 Filled Setpoint
Table 12.16 Example of Settings for Pipe-Fill Mode
116
VLT® AQUA Drive FC 202
Setting
The minimum reference unit
matches the unit in
parameter 20-12 Reference/
Feedback Unit
The maximum reference unit
matches the unit in
parameter 20-12 Reference/
Feedback Unit
(2 s)
(8 s depending on size)
(8 s depending on size)
(30 Hz)
(50/60 Hz)
⇒ Function Set-up, to
Setting
Disabled
(Feedback units)
(Feedback units)
Danfoss A/S © 05/2017 All rights reserved.
Performance
Speed
Pipe Fill Vertical Pipes
Max. speed
Fill rate units/sec.
Min. speed
Initial ramp
Filled setpoint
Illustration 12.5 Performance Curve for Pipe Fill Mode
Closed loop
Time
MG22B102
