Xycom 3400 Series Hardware Reference Manual page 29

29
Figure 3-12. 3408KP F13-F20 Insert Dimensions
1.083
(27.5)
0.828
(21.0)
FAR
SIDE
.145
(3.7)
TYP.
NEAR
1.266
(32.2)
SIDE
Note: All dimensions in inches (mm)
Material: .007 (.178) thick polyester
Figure 3-13. 3408KP Control Key Insert Dimensions
.510
(13.0)
TYP.
.074
(1.9)
2.722
(69.1)
PF1 PF2 PF3
U V W
PF4 PF5 PF6
X Y Z
.090 (2.3)
RAD
.545
(13.8)
TYP.
