3410KP and 3410KPT Front Panel

Feature
Display
IR (Ifrared) Port
PF/Function/Alpha Keypads
Control keypad
16
Figure 3-3. 3410KP Front Panel
Description
The 3410KP ships with a 10.4-inch TFT active matrix color
LCD flat-panel. An optional touchscreen (KPT) is also avail-
able.
This port is IrDA and ASKIR compliant, allowing you to con-
nect the unit to any IrDA-compatible device. You must load
special software (not included) to use this feature. When en-
abled through the BIOS Setup menu, the IR link is designed
to operate at a distance of 0 to 1 meter. Note: COM2 is not
available for other use when you select the IR port in the
BIOS Setup menus.
The keypads provide function keys F1-F20, PF keys 1-12 (PF
keys 7-12 also include punctuation symbols), as well as up-
percase letters A-Z. These keys are relegendable (refer to
Customizing Keypad Inserts later in this chapter).
This keypad provides the
, and + keys. (The
SPACE
keys are relegendable.) These keys work the same as they
do on a keyboard.
The / key toggles the keypads between function and alpha
F A
mode. When the /
F A
function mode. When you press and hold the
keypads are in alpha mode (refer to Figure 3-3 to determine
the location of the alpha characters).
, , ,
CTRL SHIFT INS ALT
, , ,
CTRL SHIFT INS ALT
key is not pressed, the keypads are in
, , , / ,
TAB DEL F A
, , and
TAB DEL
/ key, the
F A
