Xycom 3400 Series Hardware Reference Manual page 15

Refer to Chapter 4 for information on using the keypads, and Chapter 5
for information on reprogramming the keys (not currently applicable to
Windows CE).
Feature
Display
IR (Infrared) Port
Function/Alpha Keypads
Control/Alpha keypad
Numeric keypad
Cursor control keypad
15
Note
Description
The 3408KP ships with a 7.7-inch STN passive color LCD flat-panel
display with an impact-resistant shield.
This port is IrDA and ASKIR compliant, allowing you to connect the
unit to any IrDA-compatible device. You must load special software
(not included) to use this feature. When enabled through the BIOS
Setup menu, the IR link is designed to operate at a distance of 0 to
1 meter. Note: COM2 is not available for other use when you select
the IR port in the BIOS Setup menus.
The keypads provide function keys F1-F20, as well as uppercase
letters A-T. These keys are relegendable (refer to Customizing
Keypad Inserts later in this chapter).
This keypad provides the
and + keys, as well as the uppercase letters U-Z. (The
, , , and
INS ALT TAB DEL
The / key toggles the keypads between function and alpha mode.
F A
When the / key is not pressed, the keypads are in function mode.
F A
When you press and hold the
mode (refer to Figure 3-2 to determine the location of the alpha
characters).
You can also use the
F
display. To do this, hold down the
control key.
This keypad provides numbers 0-9, as well as a decimal point and
a minus sign.
This keypad controls cursor movement. It also provides contrast
control when used in conjunction with the
, , ,
CTRL SHIFT INS ALT
keys are relegendable.)
/ key, the keypads are in alpha
F A
/ key to adjust contrast on the flat-panel
A
/ key while pressing a cursor
F A
/
F A
, , , / , ,
TAB DEL F A SPACE
, ,
CTRL SHIFT
key.
