Chapter 2. Installing the RA8000 and ESA12000

2.3.2 Installing the External Cache Battery (ECB)

Install the ECBs into the into the ECB shelf of the ESA12000 or at the top of the RA8000
pedestal. Figure 2–9 shows the location of the ECB shelf in the ESA12000.
Figure 2–9 ECB Shelf Location in the ESA12000
ECB
CXO6670A
EK–SMCPR–UG. A01 387404–001 2–11
