Figure 2–40 Expansion Enclosure SCSI Bus Addresses
ID3
ID2
ID1
ID0
ID7
ID6
EK–SMCPR–UG. A01
Chapter 2. Installing the RA8000 and ESA12000
SCSI SCSI
Bus 2 Bus 4
SCSI SCSI SCSI
Bus 1 Bus 3 Bus 5
EMU PVA
Cache module Cache module
387404–001
SCSI
Bus 6
Device
Address 3/11/15
Device
Address 2/10/14
Device
Address 1/9/13
Device
Address 0/8/12
PVA
Address 0/2/3
Device
Address 7
Device
Address 6
CXO5889A
