RA8000 and ESA12000 Storage Subsystems

5.14 FRU Parts List

The Field Replaceable Units in the storage cabinet is shown in the exploded view of
Figure 5-13. Refer to Figure 5-13 to identify the FRU, and then to Table 5-2 to obtain the
description of the FRU and its corresponding part number.
Table 5–2 Subsystem Field Replaceable Units
Item Description
1 HSG80 Array Controller
HSZ80 Array Controller
2 Environmental Monitor Unit (EMU)
3 AC Power Entry Controller
4 Power Supply SBB
5 External Cache Backup (ECB)
Dual
Single
6 Dual-Speed Blower, Blue
Dual-Speed Blower, Gray
7 Single-Ended I/O Module, Blue
Single-Ended I/O Module, Gray
8 Power Verification and Addressing
(PVA)
9 Cache Module
10 DIMM, 32 MB*
11 Power Distribution Unit (PDU)**
60 Hz
50 Hz
* 64 MB, 128 MB, 256 MB, or 512 MB may be mounted in the cache module.
** The Power Distribution Unit (PDU) is used in the ESA12000 only.
5–32
COMPAQ DIGITAL
Part Number Part Number
400285-001 70-33259-S1
Not yet available 70-33252-S1
400286-001 FC-BA35X-EB
400287-001 FC-BA35X-HE
400288-001 FC-BA35X-HH
400291-001 FC-HS35X-BD
400292-001 FC-HS35X-BC
400293-001 FC-BA35X-MK
Not yet available FC-BA35X-ML
400294-001 FC-BA35X-MN
401911-001 70-32856-S2
400299-001 FC-BA35X-EC
400295-001 70-33256-S1
400296-001 70-DIMS1-01
400297-001 70DIMS1-02
401950-001 FC-SW41U-XA
401951-001 FC-SW41U-XB
EK–SMCPR–UG. A01
