2.2.4 SW42U Cabinet Rack Mount Template

If your data center cabinet is a Compaq 42U cabinet rack, use the rack mount template
supplied with the rack-mountable enclosure to select the correct mounting holes along the
side rails of the cabinet.
2.3

BA370 Major Components

Figure 2–5 shows the major components in a ESA12000 subsystem. The configuration
shown consists of one rack-mountable BA370 which contains 24 disk drive SBBs and a
single ECB (external cache battery).
Figure 2–5 ESA12000 Subsystem Major Components
1
10
EK–SMCPR–UG. A01
Chapter 2. Installing the RA8000 and ESA12000
6
4
5
2
3
9
387404–001
7
8
CXO6673A
2–5
