Chapter 2. Installing the RA8000 and ESA12000
2.5.3 Installing the AC Input Power Entry Controller
There are no external indications of a power controller failure on the ac power entry
controller itself. Both status LEDs on the power supply being off indicate a possible
power controller failure. Use the following procedure to install a new ac power entry
controller. Refer to Figure 2-42.
1. Press 0 on the ac input power entry controller ON/OFF switch.
2. Insert the ac input power entry controller into the BA370 enclosure.
3. Tighten the two retaining screws at the top and bottom of the ac input power entry
controller.
4. Connect the ac power cord to the ac input power entry controller.
5. Press I on the ac input power entry controller ON/OFF switch.
6. Observe the power supply status LEDs for proper operation.
EK–SMCPR–UG. A01 387404–001 2–55
